| Standard |
IEC/EN60947-3 |
| No.of poles |
1P,2P,3P,4P |
| Rated currents (In) |
25,32,40,50,63,80,100,125A |
| Rated voltage (Ue) |
240/415V~ |
| Rated frequency |
50/60Hz |
| Utilization category |
AC-22A |
| Short-time withstand current Icw |
12Ie, t=1s |
| Rated short-circuit making capacity Icm |
20Ie, t=0.1s |
| Rated making & breaking capacity |
3Ie, 1.05Ue, CosΦ=0.65 |
| Rated impulse withstand voltage (1.2/50) Uimp |
4,000V |
| Dielectric test voltage at Ind. Freq.for 1 min |
2kV |
| Rated insulation voltage Ui |
690V |
| Electrical life |
2,000 Cycles |
| Mechanical life |
10,000 Cycles |
| Contact position indicator |
Yes |
| Protection degree |
IP20 |
| Ambient temperature |
-5℃ to +40℃, Max.95% humidity |
| Terminal connection type |
Cable/Pin-type busbar |
| Max. terminal size for cable |
50mm² |
| Max. tightening torque |
3.5N.m |
| Installation |
Mounting on 35mm DIN rail |
| Connection |
From top and bottom |
