| Standard |
IEC60947-5-1 |
| Rated voltage US(V) |
AC230/400 50/60Hz DC24 DC48 AC24 50/60Hz |
| Rated impulse withstand voltage (1.2/50) Uimp |
4,000V |
| Rated short circuit making capacity |
20le, t=0.1s |
| Dielectric test voltage at ind. Freq. for 1min |
2kV |
| Insulation voltage Ui |
500V |
| Pollution degree |
2 |
| Rated voltage (Ue) |
AC230V |
| Rated insulating voltage(Ui) |
500V |
| Over-voltage tripping range |
280V±5% |
| Under-voltage tripping range |
170V±5% |
| Electrical life |
4,000 Cycles |
| Mechanical life |
4,000 Cycles |
| Protection degree |
IP20 |
| Ambient temperature (with daily average≤35℃) |
-5℃~+40℃ |
| Storage temperature |
-25℃~+70℃ |
| Terminal connection type |
Cable |
| Terminal size top/bottom for cable |
2.5mm2 18-13AWG |
| Tightening torque |
0.8 N.m 7In-Ibs |
